Corrugated Board Printing Machine

YK3060 Series of Flexo Printing Slotting Machine YK4860 SERIES OF Flexo Printing Slotting Machine YK530 SERIES OF Flexo Printing Slotting Machine ZKFQ4810 Series Of Automatic High-speed Slotting Machine ZYK4810 Series of Automatic High-speed Flexo Printing Slotting Die-cut Machine ZYKM3010.

Send Inquiry

Wyazs name	Unit	2200	2400
Max paper coverage	mm	980*2150	980*2350
Effective printing area	mm	980*1800	980*2000
Min finish size	mm	250*450	250*450
Thickness of printing plank	mm	6	6
Adapt to cardboard thickness	layers	3、5	3、5
Topping precision	mm	±0.75	±0.75
Slotting precision	mm	±1.0	±1.0
Max speed	Pcs/min	60	60
Economy speed	Pcs/min	30-50	30-50
power of motor	kw	1.5-7.5	1.5-7.5
Shape size	mm	404032501720	404034501720

YK4860 SERIES OF Flexo Printing Slotting Machine

Wyazs name	Unit	2500	2700
Max paper coverage	mm	1450*2450	1450*2650
Min finish size	mm	1450*2200	1450*2400
Thickness of printing plank	mm	400*500	400*500
Adapt to cardboard thickness	layers	6	6
Slot width	mm	3、5、7	3、5、7
Cut corner deepness	mm	7	7
Max.depth of slot	mm	50	50
Topping precision	mm	400	400
Slotting precision	mm	±1.0	±1.0
Max speed	Pcs/min	±2.0	±2.0
Economy speed	Pcs/min	60	60
power of motor	kw	30-50	35-50
Shape size	mm	3-7.5	3-7.5

YK530 SERIES OF Flexo Printing Slotting Machine

Wyazs name	Unit	2800
Max paper coverage area	Mm	1600*2700
Effective printing area	Mm	1600*2500
Min finish size	Mm	400*500
Thickness of printing plank	mm	6
Adapt to crdboard	Layes	3.5.7
Slot width	Mm	7
Cut corner deepness	Mm	50
Max depth of slot	Mm	400
Topping precision	Mm	±1.0
Max speed	Pcs/min	60
Economy speed	Pcs/min	30-50
Power of motor	Kw	5.5

ZKFQ4810 Series Of Automatic High-speed Slotting Machine

Wyazs name	Unit	2500	2700
Max paper coverage	mm	1500*2450	1500*2650
Skip feed paper size	mm	1850*2450	1800*2650
Min finish size	mm	400*500	400*500
Machinable cardboard thickness	layers	2-12	2-12
Slot width	mm	7.0	7
Cut corner deepness	mm	50	50
Max.depth of slot	mm	400	400
Max speed	Pcs/min	120	120
Economy speed	Pcs/min	80-100	80-100
Slotting precision	mm	±1.5	±1.5
Frequency conversion power of main motor	kw	11	11

ZYK4810 Series of Automatic High-speed Flexo Printing Slotting Die-cut Machine

Wyazs name	Unit	2500	2700
Max paper coverage	mm	1500*2400	1500*2600
Skip feed paper size	mm	1850*2400	1850*2600
Effective printing area	mm	1430*2200	1430*2400
Min finish size	mm	350*500	350*500
Thickness of printing plank	mm	6.0	6.0
Machinable cardboard thickness	layers	2-12	2-12
Max speed	Pcs/min	100	100
Economy speed	Pcs/min	70-80	70-80
Frequency conversion power of main motor	kw	7.5-22	7.5-22
Shape size(length )	mm	512032001900	512034001900

ZYKM3010 Series of Automatic High-Speed Flexo printing Slotting Die-cutter Machine

Wyazs name	Unit	2200	2400
Max paper coverage	mm	1000*2100	1000*2300
Skip feed paper size	mm	1250*2100	1250*2300
Effective printing area	mm	1000*1800	1000*2000
Min finish size	mm	250*450	250*450
Thickness of printing plank	mm	7.2	7.2
Machinable cardboard thickness	layers	3、5	3、5
Max speed	Pcs/min	120	120
Economy speed	Pcs/min	80-100	80-100
Topping precision (four colors)	mm	±0.75	±0.75
Slotting precision	mm	±1.5	±1.5
Cutting precision	mm	±1.5	±1.5
Frequency conversion power of main motor	kw	7.5-18.5	7.5-18.5
Shape size	mm	4120033001900	412035001900

YK6060 Series Flexo Printing Slotting Machine

Wyazs name	Unit	2200-3500
Max paper coverage	mm	2150-3450
Effective printing area	mm	1900-3199
Min finish size	mm	500*600
Thickness of printing plank	mm	6
Adapt to cardboard thickness	layers	3、5、7
Slot width	mm	7
Cut corner deepness	mm	50
Max.depth of slot	mm	500
Topping precision	mm	±0.75
Slotting precision	mm	±1.5
Max speed	Pcs/min	60
Economy speed	Pcs/min	30-50
power of motor	kw	7.5
Shape size	mm	4520（3120-4420）2050

YK7060 Series Flexo Printing Slotting Machine

Wyazs name	Unit	2200-3600
Max paper coverage	mm	2150-3550
Effective printing area	mm	1900-3300
Min finish size	mm	550*600
Thickness of printing plank	mm	6
Adapt to cardboard thickness	layers	3、5、7
Slot width	mm	7
Cut corner deepness	mm	50
Max.depth of slot	mm	588
Topping precision	mm	±0.75
Slotting precision	mm	±1.5
Max speed	Pcs/min	60
Economy speed	Pcs/min	30-50
power of motor	kw	11
Shape size	mm	6050（3200-4600）2000

YK8060 Series Flexo Printing Slotting Machine

Wyazs name	Unit	2200-3600
Max paper coverage	mm	2500-3550
Effective printing area	mm	2500-3300
Min finish size	mm	600*600
Thickness of printing plank	mm	6
Adapt to cardboard thickness	layers	3、5、7
Slot width	mm	7
Cut corner deepness	mm	50
Max.depth of slot	mm	667
Topping precision	mm	±0.75
Slotting precision	mm	±1.5
Max speed	Pcs/min	60
Economy speed	Pcs/min	30-50
power of motor	kw	7.5-11
Shape size	mm	5750（3300-5700）2100
