Corrugated Semi -Automatic Flute Laminator Machine

（ Technique Parameter ） : Instruction: The new type servo laminator machine adopt double frequency conversion at the front and back of the machine, automatic gluing,autom a tic washing gears, Photoelectric alignment, screw attached pressing, vacuum adsorption botto m paper, labour feeding

Send Inquiry

A. Technique Parameter:

Model	HL-1450A-I	HL-1550A-I	HL-1650A-I
Max size of laminating	1400×1250mm	1500×1250mm	1600×1250mm
Min size of laminating	360mm×360mm	360mm×360mm	360mm×360mm
Economic speed	0-100pieces/min	0-100pieces/min	0-100pieces/min
Laminating precision	±1	±1	±1
Power	6.5KW	6.5KW	6.5KW
Size	8.8×2.05×1.7m	8.8×2.15×1.7m	8.8×2.25×1.7m
Weight	About 3.5t	About 3.5t	About 3.5t

B.Instruction:
The new type servo laminator machine adopt double frequency conversion at the front and back of the machine, automatic gluing,automatic washing gears, Photoelectric alignment, screw attached pressing, vacuum adsorption bottom paper, labour feeding paper, whole machine 8.8m, mainframe 3m, pressure transfer platform 5m, paper receiving platform1.2m, 28 pressure rollers, 6 positioning belt, 1 synchronous belt, 3 Synchronous wheel, 14 paper pressing wheel, transfer platform is Stainless steel double bridge stander, wheelbase adjustment bar adopts pressure bearing, worm wheel adjustment transmission shaft is double dis double bearing and balance processing, all the main equipment parts adopt famous manufacturer from domestic and foreign, long original product life long, good stability, and ensure the reliability of electrical components in the using process.
